Professional Electric Fuel Oil Transfer Pump High Strength For Oil Stations

Professional Electric Fuel Oil Transfer Pump High Strength For Oil Stations
Professional Electric Fuel Oil Transfer Pump High Strength For Oil Stations

Large Image :  Professional Electric Fuel Oil Transfer Pump High Strength For Oil Stations

Product Details:
Place of Origin: China
Brand Name: BJB
Certification: ISO
Model Number: 3SY55
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Exported Iron Box
Delivery Time: 30 work days
Payment Terms: L/C, T/T
Supply Ability: 600 sets per year
Detailed Product Description
Usage: Crude Oil Tranfer Structure: Three-cylinder Horizontal Plunger Pump
Application: Oil Stations On The Oil Fields Body Material: Cast Iron/stainless Steel/316ss
Flow Rate: 5-20m3/h Pressure: 3-16Mpa
Power Rate: 15-55KW Seal Type: Merchanic Seal
High Light:

crude oil transfer pump

,

electric fuel transfer pump

Triplex 5-20m³/h, Max. Pressure 25Mpa Crude Oil Tranfer Pump



Description

The Power end adapts the 3-turn & 2-support crankshaft and connection rods structure. And due to the multi-cylinder pump, the discharge flow can be reduced and the inertia head can decrease to cut down the pipeline vibration. The power end mainly consists of frame, crankshaft, connection rods, crossheads, crosshead pins, connection rod bushings (Big and small ends) and rolling bearings. It features with simple structure, higher strength and rigidity, lighter weight,longer service life,convinient maintenance and stable operation.

Application

Mainly used for conveying crude oil or mediums similar to crude oil at physics property.Mainly used for transport of crude oil or other related products between different oil stations.

Specification



Model 3SY55
Plunger DN 50-85mm
Stroke    90mm
Discharge flow rate 5-20m3/h
Discharge pressure   3-16MPa
Pump power 15-55kW

Supply range



Item Product name Quantity Remark
1 Pump 1 piece
2 Motor 1 piece Selected based on the user’s need
4 Attachment 1 unit
5 Consumables 1 unit
6 Spare parts, accessories and special tools 1 unit
7 Drawings and technical documents 1 unit

Product Features

It consists of power end, plunger combination and hydraulic end as a kind of horizontal triplex or quintuplex single active recirculation pump based on the over sixty-year R&D experience and the civil fluid technology of China Academy of Lanch Vehicle Technology.

Packing & Delivery

1. Prompt deliver at the very day.
2. Sophisticated and professional logistic agent.
3. Well-trained and disciplined packing team.
4. After-sale service:Any questions or problems while operating the product, please feel free to contact us. Problems would be solved for you immediately.



Competitive Advantages

1. Over sixty experience on pump R&D,production.

2. Adapt aerospace fluid high tech on the hydraulic end and power end,

3. A-grade supplier of CNPC over ten years.

4. High quality products at competitive price in quick delivery.
5. Professional and sincere after-sale service for overseas markets.
6. Exported to USA,Canada,Iran, Zambia,Indonesia and many other countries.
